| Tyre Size |
Ply Rating |
Load Index |
Speed Symbol |
Overall Diameter(mm) |
Section Width(mm) |
Thread Width(mm) |
Thread Depth(mm) |
Rim |
Single Max L/P(kg/kPa) |
Dual Max L/P(kg/kPa) |
| 6.50R16LT |
12PR* |
110/105 |
L |
746 |
185 |
149 |
12 |
5.50F |
1060kg(2337lbs)/670kPa(97psi) |
925kg(2039lbs)/670kPa(97psi) |
| 7.00R16LT |
14PR |
118/114 |
L |
771 |
200 |
160 |
12 |
5.50F |
1320kg(2910lbs)/770kPa(112psi) |
1180kg(2600lbs)/770kPa(112psi) |
| 7.50R20 |
14PR |
130/128 |
L |
937 |
210 |
170 |
14.5 |
6.0 |
1900kg(4190lbs)/830kPa(120psi) |
1800kg(3970lbs)/830kPa(120psi) |
| 8.25R20 |
14PR |
136/134 |
L |
975 |
235 |
170 |
14.5 |
6.5 |
2240kg(4940lbs)/830kPa(120psi) |
2120kg(4675lbs)/830kPa(120psi) |
| 11R22.5 |
16PR |
148/145 |
M |
1053 |
282 |
202 |
16.5 |
8.25 |
3150kg(6940lbs)/850kPa(123psi) |
2900kg(6395lbs)/850kPa(123psi) |
| 12R22.5 |
18PR |
152/149 |
M |
1080 |
304 |
244 |
16.5 |
9.00 |
3550kg(7830lbs)/930kPa(135psi) |
3250kg(7160lbs)/930kPa(135psi) |
| 13R22.5 |
18PR |
154/151 |
K |
1117 |
318 |
240 |
16.5 |
9.75 |
3750kg(8270lbs)/850kPa(123psi) |
3450kg(7610lbs)/850kPa(123psi) |
| 295/60R22.5 |
18PR |
150/147 |
L |
921 |
286 |
241 |
16.5 |
9.00 |
3350kg(7390lbs)/900kPa(130psi) |
3075kg(6780lbs)/900kPa(130psi) |
| 295/80R22.5 |
18PR |
152/149 |
M |
1055 |
304 |
233 |
16.5 |
9.00 |
3550kg(7830lbs)/900kPa(130psi) |
3250kg(7160lbs)/900kPa(130psi) |
| 315/80R22.5 |
18PR |
156/152 |
M |
1085 |
318 |
261 |
16.5 |
9.00 |
4000kg(8820lbs)/830kPa(120psi) |
3550kg(7830lbs)/830kPa(120psi) |
| 315/60R22.5 |
20PR |
154/148 |
L |
946 |
314 |
274 |
13.5 |
9.75 |
| 315/60R22.5 |
16PR |
152/148 |
L |
946 |
314 |
274 |
13.5 |
9.75 |
3550kg(7830lbs)/900kPa(130psi) |
3150kg(6940lbs)/900kPa(130psi) |
| 315/70R22.5 |
20PR* |
156/150 |
L |
1017 |
313 |
263 |
14.5 |
9.00 |
| 315/80R22.5 |
20PR |
157/154 |
L |
1085 |
318 |
261 |
16.5 |
9.00 |
4125kg(9090lbs)/900kPa(130psi) |
3750kg(8270lbs)/900kPa(130psi) |
