On/Off Road

Drive, Trailer

● Cross groove design helps to clear water and mud away and offers excellent traction with outstanding handling characteristics, suitable for all complex road conditions. ● Special tread compound and stone-removal construction promotes resistance against cuts and punctures. ● Open shoulder and radiating grooves improve heat radiating. ● Special belt package construction enhances rigidity in tread and shoulder; superior bead design effectively reduces carcass deformation and comprehensively enhances load-carrying capacity. ● Reinforced carcass and bead improve the load-carrying capacity. ● Excellent traction ● Outstanding resistance to cuts and punctures ● Great heat-radiating performance ● Superior load-carrying capacity

Tyre Size Ply Rating Load Index Speed Symbol Overall Diameter(mm) Section Width(mm) Thread Width(mm) Thread Depth(mm) Rim Single Max L/P(kg/kPa) Dual Max L/P(kg/kPa)
10.00R20 18PR* 149/146 J 1062 278 212 19 7.5 3250kg/930kPa 3000kg/930kPa
11.00R20 18PR* 152/149 J 1092 292 226 19 8.0 3550kg(7830lbs)/930kPa(135psi) 3250kg(7160lbs)/930kPa(135psi)
12.00R20 18PR* 154/151 J 1130 310 252 19 8.5 3750kg(8265lbs)/830kPa(120psi) 3450kg(7610lbs)/830kPa(120psi)
